Features

1. These are Solenoid Operated Directional Valves of high pressure, high flow and low pressure drop, the features of which can be materialized by employing a powerful wet type solenoid and the rational flow channel design.

2． In conformity with the ISO standard, the installation is absolutely interchangeable.
3.  Connected to the common terminal, the 50HZ and 60HZ can overcome the disturbance of varied frequencies.
4.  Both plug-in solenoid easy to changeable coil.
5.  The light beaming direction of movement is distinctive.

特性

1. 濕式電磁設計、做動平穩無沖擊、噪音值低。
2. ISO標準、安裝尺寸具有絕對互換性。
3. 50Hz、60Hz共用端子結構，解決不同周波之擾。
4. 插入型電磁設計，分解組立非常容易。
5. 燈光指示做動方向，明確清楚。


Specifications性能參數

型號 Model number	最大流量 Max.flow L/min	最高使用壓力(MPa) Max working pressure	最高允許背壓 (MPa) Max back pressure	最高切換頻率(次/分) Max change over frequency	質量Mass(kg)
DSG-01-3C※-※-50 DSG-01-2D2-※-50 DSG-01-2B※-※-50	63	31.5僅滑閥機能60型25 Spool type 60 only 25	16	300	2.2
					1.6
					1.6
